1Promise SP01 Powerful Configuration Dual Band WiFi Mini Smart Pico
Pocket Projector
Features:
> Powerful Configuration
Designed to enable all kinds of exciting user experience with its
high performance flagship Quad Core ARM Cortex-A53 CPU and ARM G31
MP2 GPU.
> Multiple Interfaces
It is with TF, USB, HDMI inputs, working with TF cards, USB drive,
TV Stick, Game Console, Laptops etc.
> WiFi 2.4G/5G
It using 2.4G/5G WiFi with stable transmission without stutter,
effectively avoid signal interference.
> Enjoy Screen Mirroring
In the same network, the projector can enter the app "Eshare" to
realize screen mirroring with other devices.
| Projection Parameters |
| Resolution | WVGA 854*480 support 4K |
| Projection technology | DLP(0.2"DMD) |
| Lamp type | LED |
| Lamp brightness | 65 ANSI Lumens |
| Projection light source | RGB LED OSRAM Q6 |
| Lifetime of LED lamp(standard focus) | Up to 20,000 hours |
| Projection Area | 30-120inch |
| Contrast ratio | 500:1 |
| Projection ratio | 1.35:1(33.5 inch@1M) |
| Distortion | <1.0% |
| Brightness uniformity | >85% |
| Projection distance | 1-5m |
| Aspect Ratio | 16:9 |
| Language | Multi-language |
| Focus mode | Manual focus |
| Keystone correction | Automatic, vertical: ± 40 D |
| Projector features | Interaction |
| Projection method | Front Projection |
| Offset | N/A |
| 3D display | N/A |
| System Parameters |
| Operation system | Android 9 |
| Chipset | S905X2(Amlogic) |
| CPU | quad-core ARM Cortex-A53 CPU up to 1.8GHz (DVFS) |
| GPU | ARM G31 MP2 GPU |
| RAM | 2GB DDR3 |
| ROM | 16GB / 32GB |
| WIFI | 2.4G / 5G |
| Bluetooth | BT 4.2 |
| Touch panel control | Yes |
| Other control | IR or 2.4G wireless remote |
| Screen mirroring | Airplay/MiraCast |
| Basic Parameters |
| Interfaces | HDMI INPUT*1 |
| TF Card Max 32GB *1 |
| USB 2.0 IN*1 |
| 3.5mm Audio OUT*1 |
| 1* MICRO USB input: DC 5V 3A & OTG |
| Adaptor | AC100-240V,50/60Hz DC 5V 3A |
| Video format | VP9-10,H.265,H.264,MPEG-4,WMV/VC-1,MPEG-2,MPEG-1,RealVideo 8/9/10
etc. |
| Music format | MP3,WMA,MP2,OGG,AAC,M4A,MA4,FLAC,APE,3GP,WAV |
| Image format | Supports variety of image formats browsing (jpg, png, bmp etc.) |
| Battery capacity | 5000 MAH |
| Battery use time | About 1.5H |
| Built-in Speaker | 1*1 Watt |
| Power consumption of Lens | 3W |
| Power consumption of whole product | 8W |
| Package Detail |
| Accessories | 1*Manual
1*IR Remote Control
1*Tripod
1*Adaptor |
| Product size | 100x61x63.5mm |
| Available color | Black/Green |
| Case Material | Plastic |
| Unit weight | 320g |
| Product weight with package box | 734g |
| Package size | 173x117x80mm |
| Carton size | 44.5x18.5x26cm |
| G.W | 7.72kg |
| QTY/ CTN1 | 10pcs |
FAQ:
Q1: Do you offer OEM/ODM services?
A1: We are specialized in offering OEM/ODM services for over 16 years.
Q2: Do your factory have SMETA?
A2: Yes, we have SMETA and ISO 9001:2015.
Q3: What certificates do you have for your products?
A3: CE, ROHS, FCC, TELEC etc. These can be done as per customer's
requirements.
Q4: What is your delivery time?
A4: For sample and small order, it is normally between 3-7 working
days. For customization order, it is 20-30 work days after your
artwork are confirmed.
Q5: What about shipment?
A5: By sea, by air & express ( DHL, FEDEX, UPS, TNT, EMS...) according
to clients requirements and clients' customs policy,.
We promise to provide you the most efficient and economical
logistics.
Q6: What should I do if there is any problem with my orders?
A6: We have full healthy after-sales service system, if anything
happened not match to the contract, we shall recheck and give a
better service for customers, a full refund or free replacement if
necessary, thank you.
